DC 235 Dual Console View Gallery





Specifications

  • L.O.A. 24’ 4” (7.42 m)
  • Beam 8’ 6” (2.59 m)
  • Hull Draft  (motors up)1' 9” (0.53 m) (motors down)2' 8” (0.81 m)
  • *Clearance w/Hard-Top  (from waterline)7’ 2” (2.18 m)
  • Approx. Dry Weight  (single F300 engine)5,350 lbs (2,427 kg)
  • **Fuel Capacity 105 U.S. gallons (397 L)
  • Water Capacity 9 U.S. gallons (34 L)
  • Waste Water Capacity 13 U.S. gallons (49 L)
  • Max. Horsepower 300 hp (224 kw)
  • Deadrise 21°


*Hardtop Clearance shown does not include options which could increase this height dimension.
**Net tank capacity. The usable fuel capacity will be affected by several factors, including EPA-required fuel system components, temperature and loading of the boat. These factors will reduce the usable fuel capacity by approximately 10%

Specifications as well as standard and optional equipment are subject to change without notice. All measurements approximate. For more information and pricing, please contact your Pursuit dealer.


Performance Reports
Single Yamaha® F300 Engine

DC 235 Product Brochure - View Online
Full Line Product Catalog - View Online









The Pursuit DC 235 is packed full of comfortable seating and storage with classic styling throughout.

The value and affordability of the DC 235 is delivered through a fully appointed boat with popular options. Notable standards include plush cushions, standard porcelain marine head, cockpit bolsters and a neat assortment of fishing features.

A single dependable Yamaha F250 delivers consistent performance for a variety of water sports from board sports to cruising and fishing.






Gallery

Standard Equipment

Effective date: August 1, 2018

HULL FEATURES

  • Pursuit® Protection Plan:
    5-year hull/deck structural warranty
    5-year blister-free warranty
    2-year limited warranty
  • Pursuit Fresh White Gelcoat
  • Hand Laminated Hull with Vinyl Ester Resin and Engineered Fabrics
  • 3 Ply Resin Infused Composite Transom System
  • Infused Fiberglass Structural Grid System with Molded Finish and Integrated Bilge Water Management System
  • Foam Filled Structural Grid
  • Bronze Thru Hull Fittings Below Water Line
  • Chrome over Bronze Thru Hull Fittings Below the 7 Degree Heel Line
  • Stainless Clad Composite Thru Hull Fittings Above the 7 Degree Heel Line
  • Bronze Garboard Drain
  • Trim Tabs, Lenco Electric with Auto-Retract
  • Bow Eye, 1/2" 316L Stainless Steel
  • Stern Eyes (2), 1/2" 316L Stainless Steel
  • Basic Floatation
  • Integrated Transom Platform Extensions Outboard of Engine
  • Boarding Ladder, 3-Step Telescopic, Mounted in Hull Platform
  • Forward Bilge Pump with Automatic Float Switch, 900 GPH
  • Rope Locker, Self-draining
  • Anchor Scuff Plate
  • Horn, Electric, with Oval Stainless Steel Cover
  • Dedicated Transducer Location

DECK FEATURES

  • Hull and Deck Joint Mechanically Fastened
  • Rub Rail: High Density PVC with Vinyl Insert
  • Molded One Piece Deck and Cockpit Liner with Non-Skid Pattern Area
  • Flush Mounted Integral Anchor Locker with Fiberglass Lid
  • Anchor Roller Chute / 8" Cleat, 14lb Galvanized Plow Style Anchor and 150' Rode (1/2" 8 Plait)
  • Cleats, 316 Stainless Steel, 8" Pop Up (2) Stern, (2) Spring and (2) Bow
  • Molded Recessed Hatches with Gaskets and 316L Stainless Steel Latches and Overboard Drain Tracks
  • Molded Transom Walkthrough with Hinged Transom Door, 316L Stainless Steel Latch and Magnetic Catch
  • Self-Draining Cockpit with Bronze Ball Valve at Hull Side
  • Bow Grab Rails, 316L Stainless Steel (port & starboard)
  • Transom Grab Rail, 316L Stainless Steel, (starboard)
  • Navigation Lights, LED, 2 mile

COCKPIT FEATURES

  • Molded Fiberglass Windshield Frame with Tempered Glass Windshield and a Center Walk-through Door
  • Drink Holders, 316L Stainless Steel, (2) Bow, and (2) in Gunwale
  • Custom Cockpit Upholstery with Dri-Fast Foam and Mesh Backing
  • Bow Seating with Insulated Storage Below
  • Port and Starboard Forward Coaming Boxes with USB Charger Port
  • Helm Seat (sliding and swivels) with Integrated Armrests and Flip-up Bolster
  • Companion Seat with Intergraded Storage Below
  • Port Convertible Lounge, Aft Facing with Intergraded Storage Below
  • Entertainment area: Sink with Pull-out Sprayer, Insulated Cooler with Fiberglass Lid
  • Raw Water Outlet in Cockpit with Quick Connect Fittings and 25' Hose
  • LED Cockpit Accent Lights (5)
  • Folding Transom Seat with Patented Adjusting Backrest
  • Folding Stern Light
  • Ski/rod Midship Floor Storage
  • Sunbrella Bow Tonneau Cover
  • 12v DC MDP Panel with Battery Switches

FISHING FEATURES

  • Rod Holders (4), Stainless Steel, in Gunwales
  • Lighted Oceana Blue 15 Gallon Recirculating Insulated Live Well
  • Storage, Insulated, Under Bow Seats

HELM

  • Molded Console with Fixed Helm and Integrated Footrest
  • Hydraulic Steering Pump
  • 316L Stainless Steel Steering Wheel on Tilt Helm
  • 12V Panel with Illuminated Carling® Rocker Switches
  • Compass
  • Trim Tab Control Panel and Indicator
  • 12V Outlet (1)
  • Helm Fire Extinguisher
  • Visor
  • Starboard Coaming Box/Cup Holder & Storage
  • Yamaha® Command Link Plus Display

CONSOLE (STARBOARD SIDE)

  • Molded Fiberglass Lined Storage with Acrylic Door under Helm
  • Integrally Switched 12V Overhead Light
  • Table Storage
  • Dedicated Dock Line Storage
  • Dedicated Trash Receptacle Storage

HEAD (PORT SIDE)

  • Two Piece Fiberglass Door with Gasket, Integrated Storage/Visor, Grab Rail and 316 Stainless Steel Locking Latch
  • Molded Fiberglass Interior
  • Manual Porcelain (freshwater) Head with 13 Gallon Holding Tank and 316L Stainless Steel Pump-out Fitting
  • Sink with Pullout Freshwater Shower
  • Integrally Switched 12V Overhead Light
  • Toilet Tissue Holder

WINDSHIELD

  • Molded Fiberglass Windshield Frame with Tempered Glass Windshield and a Center Walk-through Door

ELECTRICAL SYSTEMS

  • UL® Rated Fully Tinned, Color Coded Copper Wire
  • Custom In-House Built, Heat Sealed, Mechanically Crimped, Color Coded Battery Cables
  • Custom In-House Built, One-Piece Electrical Harness with Water Proof Connectors and Chafe Protection
  • Powder Coated, Aluminum, Screen Printed (Front and Back) Battery Switch and Breaker Panel
  • Two Battery System: Engine (1) and House (1)
  • One Grounding Bus Bar
  • Electronics Fuse Block

MECHANICAL SYSTEMS

  • Molded Interior White Gel Coat
  • Molded Removable Access Hatch
  • Molded bilge sump area
  • One 900 GPH Low Profile Bilge Pump with Integrated Float Switch and Stainless Steel Clad Composite Thru Hull Fitting
  • 1100 GPH Tournament Series Live well Pump, Sea Cock and Thru Hull Fitting
  • Pressure Sensing Raw Water Pump with In-Line Filter

FUEL SYSTEMS

  • EPA Compliant Lined 105 Gallon Rotomolded Fuel Tank with Engine Pickup, Shutoff Valve, Digital Level Indicator and Deck Fuel Fill Plate
  • Custom Built Premium Fuel Feed Lines with Mechanically Crimped Fittings
  • Yamaha® Water Separating Fuel Filter with Primer Bulb

WATER SYSTEM

  • 9 Gallon Water Tank and 316L Stainless Steel Deck Fill Plate
  • Premium Sea Tech Color Coded Water Hose System with Mechanically Crimped Ends

Pursuit reserves the right to change boat specifications, equipment, color schemes, and pricing, and/or discontinue models at any time without notice or obligation.
Some of the boats shown include optional or dealer-installed equipment.





Optional Equipment

BOAT w/ENGINES

  • NATIONALLY ADVERTISED PROMOTION
    Single Yamaha® Digital F250
  • Upgrade to Single Yamaha® Digital F300 Engine w/Power Steering (Pearlescent White)
  • Teleflex® Power Steering (standard w/Yamaha F300)
  • Fresh White Painted Engine w/Platinum Graphics (standard w/Yamaha F300)

COLOR SELECTIONS

  • Hull Color
    • Titanium
    • Neptune Gray
    • Pursuit Flag Blue
    • Gulf Stream Blue
  • Helm Color
    • Titanium - Standard
    • Neptune Gray
    • Pursuit Flag Blue
    • Gulf Stream Blue
  • Boot Stripe Color
    • Black/Black - Standard
    • Navy/Navy
    • Platinum/Platinum
    • Red/Red
    • Scarlet/Scarlet
    • Arctic White/Quartz Gray

MECHANICAL SYSTEMS

  • Windlass Anchor System (Lewmar w/Remote)
  • Stainless Steel Delta Anchor
  • All Color Sea Blaze Quattro Spectrum Underwater Lights (2)
  • LED Mid-Level Accent Lights (4)
  • Hard Rub Rail w/SS Cap

COMFORT & CONVENIENCE

  • Bow Table w/Filler Cushion
  • Transom Mount Ski Tow

WEATHER

  • Fiberglass Hardtop w/Connector and Side Curtains
  • Bimini Top w/Connector and Side Curtains - Sunbrella®
  • Sunbrella® Canvas color - Black, Tweed, Cadet Gray, or Navy
  • Upgraded canvas - Stamoid® - White
  • Hardtop Drop Curtain - Sunbrella®
  • Hardtop Drop Curtain - Stamoid® (white)
  • Hardtop Aft Curtain - Sunbrella®
  • Hardtop Aft curtain - Stamoid® (white)
  • Bimini Top Aft Curtain - Sunbrella®
  • Bow Tonneau Cover - Stamoid® (white)
  • Instrument Cover - Sunbrella®
  • Engine Cover - Sunbrella®

SPORT FISHING

  • Hardtop Rod Holders (4)
  • Transom Rod Holders (2)

ELECTRONICS

  • JL Audio Stereo AM/FM/USB Bluetooth w/4 Speakers
  • Garmin Electronics Package
    Includes: GPSMAP 7612XSV Display, Airmar B117 0-7, Degree 600 Watt Transducer, NMEA 200 Starter Kit, Pursuit Custom Dash Panel, VHF 300, VHF Antenna Galaxy 5225XP
