Specifications

  • L.O.A. 37’ 11” (11.56 m)
  • Beam 12' 0" (3.66 m)
  • Hull Draft  (motors up)2’ 3” (0.69 m) (motors down)3’ 5” (1.04 m)
  • **Clearance w/Hardtop  (from waterline)8’ 10” (2.69m)
  • Approx. Dry Weight  (triple F300 engines)16,659 lbs. (7,556 kg)
  • *Fuel Capacity 425 U.S. gallons (1,609 L)
  • Diesel Generator Tank 20 U.S. gallons (76 L)
  • Fresh water Capacity 45 U.S. gallons (170 L)
  • Holding Tank Capacity 20 U.S. gallons (76 L)
  • Livewell Capacity 28 U.S. gallons (106 L)
  • Fishbox Capacity 2 @ 45 U.S. gallons
    (2 @ 170 L)
  • Max. Horsepower 1050 hp (783 kw)
  • Deadrise 20°


*Net tank capacity.
The usable fuel capacity will be affected by several factors, including EPA-required fuel system components, temperature and loading of the boat. These factors will reduce the usable fuel capacity by approximately 10%.
**Hardtop Clearance shown does not include options which could increase this height dimension.

Specifications as well as standard and optional equipment are subject to change without notice. All measurements approximate. For more information and pricing, please contact your Pursuit dealer.


Performance Reports
Triple Yamaha® F300 Engines

S 368 Product Brochure - View Online
Full Line Product Catalog - View Online









The Pursuit Sport series of center consoles reached new heights with the introduction of the flagship Pursuit S 408 during the 2016 Miami International Boat Show. The all new Pursuit S 368 will deliver on that same level of excitement. At a LOA of just over 37 feet, the S 368 will carry her own next to the flagship S 408. The exterior profile is just as stunning with the same industry leading features like integrated hardtop and windshield systems, transom extensions and great styling detail that set a new standard for class in luxury center consoles.

The console includes such modern amenities as a fully enclosed head, convertible sofa berth, large storage areas and some small kitchen amenities that would let you stay aboard if you desire.

On deck, distinct social zones in the bow area, at the helm and aft in the cockpit give plenty of space for an entire family and friends to find their own space. If it’s not socializing but fishing you’re after, all the amenities are included.



Gallery

Standard Equipment

April 4, 2017

HULL, DECK & COCKPIT

  • Pursuit® Protection Plan:
    5-year hull/deck structural warranty
    5-year blister-free warranty
    2-year limited warranty
  • Hand Laminated Hull with Vinyl Ester Resin and Engineered Fabrics
  • Infused Fiberglass Structural Grid System with Molded Finish and Integrated Bilge Water Management System
  • 5 Ply Resin Infused Composite Transom System with Patented Transom Reinforcement Grid
  • Integrally Molded Thru-Stem Anchor System with Fresh and Raw Water Washdown
  • Horizontal Anchor Windlass with Switch at Helm and Remote Switch at Anchor Locker
  • 22lb 316L Stainless Steel Plow Style Anchor, G-4 Chain, 200’ of 1/2”, 8 Plait Rode and Self-Righting Swivel
  • 316L Stainless Steel Through Stem Anchor Roller with 8” Mooring Cleat, Chain Binder and Aluminum Backing Plates
  • 3.0HPBowThrusterwithGroup31AGMBattery
  • Electric Oval Horn with Stainless Steel Cover
  • Lenco Electric Trim Tabs, Control pad with Indicator Lights and Auto-Retract
  • Bronze Thru Hull Fittings Below Water Line
  • Chrome over Bronze Thru Hull Fittings Below 7 Degree Heel Line
  • Stainless Clad Composite Thru Hull Fittings Above the 7 Degree Heel Line
  • Bronze Garboard Drain
  • Integrated Transom Platform Extensions Outboard of Engines
  • 4 Step Telescopic Boarding Ladder Mounted in Hull Platform
  • Forward Hull Compartmentation with one (1) 1100 GPH Bilge Pump with Automatic Float Switch
  • High Density PVC Rubrail with Solid 316L Stainless Steel Insert, Molded Rubrail Corners and 316L Stainless Steel Transom Cap
  • 1⁄2“ 316L Stainless Steel Bow Eye
  • Molded One Piece Deck and Cockpit Liner with Non-Skid Pattern Area Hull and Deck Joint Mechanically Fastened
  • Six (6) 10” Pop Up Cleats on Stern, Spring, and Bow • Flush Mounted Integral Anchor Locker with Fiberglass Lid
  • Two-Piece Welded 316L Stainless Steel Forward Deck Grab Rail Recessed into Deck with Aluminum Backing Plates
  • Bow Seating. Ability to Sit Facing Forward, Clear Passage Forward (Removable Jumpseat)
  • Insulated Storage Under Bow Seating Area Port and Starboard
  • Forward Table (High Gloss) with removable bases for dining, designated storage
  • Bow Sunpad Chaise for two (2) with Fold-Down Armrests and Drink Holders
  • Storage Under Bow Sunpad Chaise with Consideration for Common Boating Equipment. Should be able to accommodate a combination of: flexible rod/pole holders, two (2) 5-gallon pails, four (4) scuba tanks, Brownie’s 3rd Lung equipment, cooler 52 qt, and fenders
  • 316L Stainless Steel Deck Plates for Water, Waste and Diesel • Under Gunwale (Covering Board) Rod Storage, Port
  • Molded 2” Transom Walkthrough and Hinged Acrylic Transom Door with 316L Stainless Steel Latch and Positive Catch
  • Molded Non-Skid Step in Splashwell for Athwartship Access and Integrated Rigging
  • Port and Starboard 316L Stainless Steel Transom Grab Rails
  • Custom Cockpit Upholstery with Dri-Fast Foam and Mesh Backing
  • Pursuit Cockpit Entertainment System: JL Media Master 12V Bluetooth® Compatible Stereo System, Premium Speakers eight (8) Total, six (6) in Exterior and two (2) Subwoofers), Amplifier and Remote at Helm
  • Molded Entertainment Center with Molded Sink, Hot/Cold Mixing Faucet, Dedicated Storage, 120V Outlet with GFI Protection and Hinged Fiberglass Lids/Doors
  • Folding Transom Seat with Patented Adjusting Backrest
  • Helm Seat Box Content
    • Frig 2.3 cub ft with pull-out drawer (Isotherm) (port side)
    • DC Panel and Battery Switch access under helm seat (Starboard side)
    • Large storage compartment (trunk) under aft facing mezzanine seat
    • Electric Grill 120V 60 cycle in Pull-out Drawer
  • 316L Stainless Steel Drink Holders ; Bridge, Cockpit and Helm
  • Cockpit Machinery Access Hatch
  • Fresh Water Cockpit Shower with Hot/Cold Mixing Valve and Pull out Sprayer
  • Raw Water Outlet in Cockpit with Quick Connect Fittings and 25’ Hose
  • Port and Starboard Combo 2 mile LED Navigation lights
  • Self-Draining Cockpit with Scupper Drains Bronze Ball Valves and Elbows
  • Full Cockpit Breathable Coaming Bolsters with Dry Fast Foam
  • Inward Opening Side Boarding Door Starboard Side with Removable/Storable Ladder for Water Play
  • Seven (7) LED Cockpit Courtesy Lights:
    • Two (2) Lights at Bridge Deck
    • Three (3)Lights at Bow Seating and Walkways – Two (2) Lights at Cockpit Steps
    • Cockpit Fire Extinguisher Under Mezz Seat
  • Dockside Fresh Water Inlet with Pressure Regulator

FISH FEATURES

  • Four 316L Stainless Steel Rod Holders in Gunwale with two (2) Drink Holders
  • Lighted Oceana Blue 28 Gallon Recirculating Livewell
  • Port and Starboard 45 Gal Insulated Fishboxes in Cockpit with Dedicated Discharge Pumps
  • Aluminum Reinforcement Plates and Wiring for Downrigger Installation, Port and Starboard
  • Raw Water Outlet with Speed Tap Hose and Sprayer
  • Lockable Storage for four (4) Rods under Fwd Seats
  • Open Storage Under Port Gunwhale for three (3) Rods

HARDTOP

  • Integrated Fiberglass Hardtop with Visor
  • White Powdercoated Hardtop Supports with two (2) Rod holders, with integrated ladder rungs for access to hardtop
  • Tempered Windshield Glass, Tempered Side Glass with Fiberglass Frame and Electrically Actuated Center Vent Window
  • Single Windshield Wiper with Fresh Water Washer
  • Hinging Combination Anchor/Stern LED All-around Navigation Light.
  • Four (4) Tri Color LED Lights
  • Two (2) Aft Facing Spreader Lights, one (1) Fwd Facing Spreader Light
  • Life Jacket Storage • Overhead Displays, AutoPilot Display, Yamaha Display

HELM

  • Molded Fiberglass Aft Tilting Helm with Instrumentation Visor, Electronics Mounting Surface, and Safety Lanyard
  • Platform for low-eye position fold down from seat box
  • Molded Acrylic Access Door with Secondary Framed Screen Door and 316L Stainless Steel Locking Latch
  • Port Fold-down Footrest
  • Teleflex Tilt Sport Helm
  • 316L Stainless Steel Steering Wheel with Textured Grip and Control Knob
  • Top Load Glovebox (Starboard side), (contains USB charging port)
  • Pursuit Custom Triple Captain’s Seats with Folding Armrests, three (3) Sculpted Flip-Up Bolsters and Lumbar Support, one (1) medium on ramping actuator, two (2) small stationary
  • Single Independent Windshield Wiper Washer Control
  • Ritchie® Navigator Compass
  • Bow Thruster Joy Stick Control
  • 12V Switch Panel
  • Trim Tab Control Panel and Indicator
  • Waterproof JL Media Master Stereo Remote
  • Two (2) drink holders
  • Two (2) 12V Outlets and one (1) Dual USB Charger
  • Helm Fire Extinguisher
  • Nonskid Helm Floor Area

INTERIOR CABIN

  • Full Fiberglass Cabin Deck Liner with Sound Damping Insulation
  • Full Fiberglass Hull Liner with Sound Damping Insulation
  • Cabin Entry Steps with Custom Handrail and Wood Treads
  • Custom Solid Wood Tongue and Groove Floor Accents, Mechanical Access and Drainage
  • Forward Berth with 4” Foam Cushions and Storage Beneath
  • Port and Starboard Forward Outboard Storage
  • 316L Stainless Steel Opening Port Lights two (2) with Screen
  • 12V Outlet one (1) and Dual USB Charger one (1)
  • Companionway 2-Switch Panel:
    • Two (2) Accent Floor Lights
    • Two (2) Overhead LED at Companionway
    • four (4) Overhead LED at berth
  • 1.1 ft3 120V Microwave Oven
  • CO Monitor
  • Fire Extinguisher
  • AC Panel with strip light
  • Storage in front of berth

HEAD (STARBOARD)

  • Fiberglass Private Head Compartment with Non-Skid Pattern Area
  • Corian® Countertop with Sink and Storage Cabinet Below
  • Vacu-Flush Marine Head with 20 Gallon Holding Tank, Macerator Discharge Pump, Deck Pump-out Fitting and Bronze Through Hull Fitting
  • Upper Vanity Mirrors
  • Toilet Tissue Holder
  • Grab Rail/Towel Rack
  • Shower Sump Box Drain with Automatic Discharge
  • Shower with Hot/Cold Mixing Valve, Shower Wand (Pull out from Faucet)
  • Two-Switch Panel with two (2) Overhead LED Lights, one (1) LED Floor Accent Light
  • One (1) 120V Outlet with GFI Protection
  • Shower Curtain

ELECTRICAL SYSTEM

  • UL® Rated Fully Tinned, Color Coded Copper Wire
  • Custom Built, Heat Sealed, Mechanically Crimped, Color Coded Battery Cables
  • Custom Built, One Piece Electrical Harness with Water Proof Connectors and Chafe Protection
  • Powder Coated, Aluminum, Screen Printed (Front and Back) Main Breaker Panels
  • Bonding System: Thru Hull Fittings Below Water Line, Trim Tabs, Zinc Anode and Garboard Drain
  • 120V 30 Amp 60 Cycle Dockside Power Connection
  • 120V 30 Amp 50’ Dockside Power Cord
  • Pursuit Custom 12V and 120V Interior MDP Switch Panel for Cabin Interior Circuits
  • Four (4) 120V Outlets with GFI Protection
  • Four (4) 12V Outlets and two (2) Dual USB Chargers
  • Six (6) Battery System: one (1) Port Engine, one (1) Center Engine, one (1) Starboard Engine, one (1) Bow Thruster (AGM, two (2) House (AGM)
  • One (1) 40 AMP Battery Charger For House, and Bow Thruster Bank
  • One (1) 20 AMP Battery Charger for Engine Bank
  • One (1) Grounding Bus Bar • IsolationTransformer

MECHANICAL SPACE

  • Molded Interior White Gel Coat Structural Foundation
  • Molded Hatch with Gasket and Stainless Steel Gas Spring
  • Molded Bilge Sump Area
  • One (1) 900 GPH Bilge Pump with Automatic Float Switch, One 1500 GPH Bilge Pump with High Water Float Switch and Alarm with Stainless Steel Clad Composite Thru Hull Fittings
  • Fresh Water Pump with Filter
  • Raw Water Pump with Bronze Sea Strainer, Sea Cock and Thru Hull Fitting
  • Livewell Cyclone Pump with Bronze Sea Strainer
  • Teleflex Power Steering Pump
  • Bilge High Water Alarm

FUEL SYSTEM

  • EPA Compliant Lined 420 Gallon Rotomolded Fuel Tanks with Engine Pickups, Shutoff Valves and Digital Level Indicator.
  • Custom Built Fuel Lines with Mechanically Crimped Fittings
  • Three (3) Yamaha® Water Separating Fuel Filters with Primer Bulbs

WATER SYSTEM

  • 45 Gallon Water Tank with Level Indicator
  • 6 Gallon Stainless Steel Hot Water Heater 120V 60 Cycle
  • Custom Built Reinforced Color Coded Water Hose
  • Pressure Sensing Pump
  • Dockside Fresh Water Inlet With Pressure Regulator
  • Cockpit Shower with Hot/Cold Mixing Valve
  • 16 Circuit Water Distribution Manifold with Dedicated Valves

Optional Equipment

BOAT w/ENGINES:

  • Triple Yamaha® F300 Engines
    with Command Link Plus

COLOR SELECTIONS:

  • Pursuit Titanium hull
  • Pursuit Cashmere hull
  • Pursuit Navy Blue hull
  • Pursuit Stars and Stripes Blue hull
  • Graphite Interior Fabric
  • Indigo Interior Fabric
  • Twin Fresh White Painted Engines w/Platinum Graphics
  • Boot stripe color - navy blue, black, red, scarlet, platinum
  • Boot Stripe - Artic White/Quartz Gray (Used with Titanium, Navy Blue)
  • Boot stripe color - artic white/sand castle (only available with cashmere hull color)
  • Helm color - Titanium, Cashmere, Navy Blue, Stars and Stripes
  • Sunbrella® canvas color - black, tweed,
    cadet grey or navy blue

MECHANICAL SYSTEMS:

  • Yamaha® Helm MasterTM Steering System Control with Single Joystick Operation
  • Garmin® Package (GPSMAP 7616XSV Display, GPSMAP 7616 Display, Airmar B165 20 Degree 1KW Transducer, NM 2000 Starter Kit, Pursuit Custom Dash Panel, Yamaha Gateway with Cable, VHF 300, VHF Antenna Galaxy 5225XP
  • Garmin® Reactor Corepack with Smartpump Auto Pilot
  • Garmin® Reactor Corepack with Smartpump Auto Pilot (with Helm Master)
  • Garmin® Radar Open Array GMR 424 XHD2
  • Yamaha Gateway for Garmin® Electronics (with Helm Master)

WEATHER GROUP:

  • Aft Seating Covers, Weathermax®
  • Fwd Bow Seating Cover, Weathermax®
  • Fwd Sunpad Cover, Weathermax®
  • Engine Covers, three (3), Sunbrella®
  • Helm Seat Cover, Weathermax®
  • Instrumentation cover, Weathermax®
  • Three-sided enclosure Stamoid®
  • Side Winged Panels, Gunwale Mounted Stamoid®

INDIVIDUAL OPTIONS:

  • Bow Tow Eye
  • Makefast Aft Sunshade
  • Fwd Med Sunshade
  • Hardtop Mounted Top Gun with 18’ Telescoping Poles
  • Hardtop Rocket Launcher with seven (7) Rod Holders
  • Four (4) Underwater lights (Blue/White Combination)
  • ACR RCL-100D Spotlight on Hardtop with Remote Controls at Helm
  • Aft Cockpit Table (High Gloss) with Dedicated Storage Attaches to Aft wall of Seatbox for use by Mezz seat
  • Transom Rod Holders, three (3)
  • 120V/60 Cycle 4.2 kW Fischer Panda® Diesel Generator with Sound Shield and Service Slide with EPA Compliant Lined 20 Gallon Fuel Tank with Engine Pickups, Shutoff Valves and Digital Level Indicator, with FireBoy pull located on Helm Seat Box
  • 120V/60 Cycle Interior Air Conditioning with Reverse Cycle Heat and Sound Shield. 6,000 BTU Self Contained Unit for Cabin Interior with Bronze Sea Strainer, Seacock and Thru Hull Fitting (generator required)
  • 120V/60 Cycle Cockpit Air Conditioning with Reverse Cycle Heat. 6,000 BTU Self Contained Unit for Exterior Bridge Area with Bronze Sea Strainer, Seacock and Thru Hull Fitting (generator required)
