S 280 Sport View Gallery



Specifications

  • L.O.A. 28’ 0” (8.53 m)
  • Beam 9’ 6” (2.9 m)
  • Hull Draft  (motors up)1' 7” (0.48 m) (motors down)2' 10” (0.86 m)
  • Clearance w/Hardtop  (from waterline)7’ 11” (2.41 m)
  • *Clearance w/Windshield  (from waterline)6’ 3” (1.91 m)
  • Approx. Dry Weight  (w/twin 250 engines)8,380 lbs (3,801 kg)
  • **Fuel Capacity 220 U.S. gallons (833 L)
  • Fresh Water Capacity 18.5 U.S. gallons (70 L)
  • Holding Tank Capacity 20 U.S. gallons (76 L)
  • Livewell Capacity (opy.) 45 U.S. gallons (170 L)
  • Fishbox Capacity 45 U.S. gallons transom (170 L)
  •  2 @ 29 U.S. gal (2 @ 110 L))
  • Max. Horsepower 600 hp (447 kw)
  • Deadrise 24°


*Hardtop Clearance shown does not include options which could increase this height dimension.
**Net tank capacity. The usable fuel capacity will be affected by several factors, including EPA-required fuel system components, temperature and loading of the boat. These factors will reduce the usable fuel capacity by approximately 10%

Specifications as well as standard and optional equipment are subject to change without notice. All measurements approximate. For more information and pricing, please contact your Pursuit dealer.


Performance Reports
Twin Yamaha® F250 Engines
Twin Yamaha® F300 Engines

S 280 Product Brochure - View Online
Full Line Product Catalog - View Online





The Sport family of luxury center consoles starts at 28 feet and delivers a refined level of amenities enhancing the fishing experience.

The Pursuit S 280 features stunning good looks combined with exceptional handling and performance.

Its long list of standard features includes rich teak accents, a fiberglass hardtop with a white powder coated aluminum frame, an overhead electronics box, an overhead storage bag, integral overhead interior lighting and so much more.


Gallery

Standard Equipment

Effective date: AUGUST 1, 2017

HULL FEATURES

  • Pursuit® Protection Plan:
    5-year hull/deck structural warranty
    5-year blister-free warranty
    2-year limited warranty
  • Pursuit Fresh White Gelcoat
  • Hand Laminated Hull with Vinyl Ester Resin and Engineered Fabrics
  • 5 Ply Resin Infused Composite Transom System
  • Infused Fiberglass Structural Grid System with Molded Finish and Integrated Bilge Water Management System
  • Floatation Foam Filled Structural Grid
  • Bronze Thru Hull Fittings Below Water Line
  • Chrome over Bronze Thru Hull Fittings Below the 7 Degree Heel Line
  • Stainless Clad Composite Thru Hull Fittings Above the 7 Degree Heel Line
  • Bronze Garboard Drain
  • Trim Tabs, Lenco Electric with Auto-Retract
  • Bow Eye, 5/8" 316L Stainless Steel
  • Stern Eyes (2), 5/8" 316L Stainless Steel
  • Anchor System, Integrally Molded Thru-Stem
  • Horn, Electric, with Oval Stainless Steel Cover
  • Dedicated Transducer Location

DECK FEATURES

  • Hull and Deck Joint Mechanically Fastened
  • Rub Rail: High Density PVC with Solid 316L Stainless Steel Insert
  • Molded One Piece Deck and Cockpit Liner with Non-Skid Pattern Area
  • Flush Mounted Integral Anchor Locker with Fiberglass Lid including: Horizontal Anchor Windlass with Switch at Helm and Remote at Anchor Locker 316L Stainless Steel through Stem Anchor Roller with 8" Mooring Cleat, Chain Binder, 14lb Stainless Steel Plow Style Anchor, Self-Righting Shackle and 200' Rode (1/2" 8 Plait including 10’ of ¼" G4 Chain)
  • Cleats, 316 Stainless Steel, 8” Pop Up (2) Stern, (2) Spring and (2) Bow
  • Self-Draining Cockpit with Bronze Ball Valve at Hull Side
  • Molded Recessed Hatches with Gaskets and 316L Stainless Steel Latches and Overboard Drain Tracks
  • Molded Transom Walkthrough with Hinged Transom Door, 316L Stainless Steel Latch and Positive Catch
  • Bow Grab Rail, 316L Stainless Steel
  • Transom Grab Rails, 316L Stainless Steel, (port & starboard)
  • Navigation Lights, LED, 2 mile

COCKPIT FEATURES

  • LED Cockpit Accent lights (4)
  • Drink Holders (6), Stainless Steel
  • Custom Cockpit Upholstery with Dri-Fast Foam and Mesh Backing
  • Forward Bow Seating Cushions with Bolsters and Folding Backrest
  • Raw Water Outlet in Cockpit with Quick Connect Fittings and 25' Hose
  • Folding Transom Seat with Patented Adjusting Backrest
  • Boarding Ladder, 316L Stainless Steel, Telescoping with Fiberglass Hatch
  • Molded Fiberglass 2-piece Leaning Post on a Slider with Armrests, Teak Accents Aft-facing Fold-down Seat, and Port-side Storage Locker with Acrylic Door
  • Isotherm® Stainless Steel Drawer Refrigerator

FISHING FEATURES

  • Rod Holders (4), Stainless Steel, in Gunwales
  • Under Gunwale Rod Storage with Padded Reel Protectors (port & starboard)
  • Fish Boxes, in-deck (2 x 29 gallon) Insulated and Diaphragm Pumps with Overboard Discharge (port & starboard)
  • Aft Slide-out Tackle Center with Removable Storage Trays
  • Bait Prep Station with Molded Rigging Cutouts, Sink with Pull-out Fresh Water Sprayer
  • Aluminum Reinforcement Plates for Downrigger Installation, Aft Gunwale (port and starboard)

COMMAND CONSOLE

  • Integral fiberglass foot rest
  • Molded insulated 140 quart cooler with 3" cushion
  • Fiberglass hardtop and liner with white, powder coated aluminum frame, overhead strg box, 3 sprdr lights, canvas storage pouch with front and side enclosed, 6 overhead LED tricolor lights
  • Enclosed compartment with electric head, 20 gal. Holding tank, macerator and pressure stainless steel water sink
  • Stainless steel portlight with screen
  • 12 v interior lighting
  • Tempered glass windshield
  • Two 12 v receptacle at helm
  • JL Audio stereo with Bluetooth streaming and 4 speakers
  • Molded split bow seating with 4" cushions (2)

INSTRUMENTATION, EQUIPMENT & SAFETY

  • Hydraulic steering with sport adjustable helm
  • 14.5” comfort grip stainless steel steering wheel with knob
  • Master circuit breaker box
  • Three battery switch with battery and trays
  • 12 v electrical panel with breakers
  • 110 v/60 cycle dockside power with 20 amp battery charger
  • 20 gallon fresh water with Sea Tech hose
  • U.S.C.G. and international lighting
  • Automatic bilge pumps (2)
  • Fire extinguishers (3)
  • Console mounted forward facing horn and Ritchie compass
  • Pursuit meets all applicable USCG and NMMA standards
  • Yamaha® fuel management system (standard with Yamaha® engines)

Pursuit reserves the right to change boat specifications, equipment, color schemes, and pricing, and/or discontinue models at any time without notice or obligation.
Some of the boats shown include optional or dealer-installed equipment.





Optional Equipment

BOAT w/ENGINES:

  • Twin Yamaha® Electronic F300 (Power Steering Standard)

COLOR SELECTIONS

  • Hull Color
    • Titanium
    • Cashmere
    • Pursuit Flag Blue
    • Pursuit Navy Blue
  • Helm Color
    • Titanium - Standard
    • Cashmere
    • Navy Blue
    • Stars & Stripes
  • Boot Stripe Color
    • Black/Black - Standard
    • Navy/Navy
    • Platinum/Platinum
    • Red/Red
    • Scarlet/Scarlet
    • Artic White/Quartz Grey
    • Artic White/Sand Castle – Cashmere Hull Only
  • Twin Fresh White Painted Engine w/Platinum Decals

MECHANICAL SYSTEMS

  • Blue/White Underwater Lights (4)

COMFORT & CONVENIENCE

  • Poly Sunpad Filler w/Cushion
  • Forward Teak Table w/Cover

WEATHER

  • Sunbrella® Canvas Color:
    Black, Tweed, Cadet Grey or Navy
  • Upgraded Canvas - Stamoid® (White)
  • Aft curtain - Stamoid® (white)
  • Aft curtain - Sunbrella
  • Console Cover - Sunbrella
  • Leaning Post Cover - Sunbrella
  • Engine Covers - Sunbrella

SPORT FISHING

  • Bolt-on Hardtop Rod Holders (3)
  • Revolution Hardtop Mounted Outriggers w/18' Telescoping Poles
  • 45 Gallon Live Bait Well (in lieu of fishbox)

ELECTRONICS

  • Garmin Electronics Package
    Includes: GPSMAP 7612XSV 12" Display, 7612 12" Display, Airmar B164 20 Degree 1KW Transducer, NMEA 2000 Starter Kit, VHF 300, VHF Antenna, Galaxy 5225XP, Custom Pursuit Dash Panel
  • Garmin 48 Mile Radar
