C 260 Center Console View Gallery 360º Tour



  • L.O.A. 25’ 10” (7.87 m)
  • Beam 8’ 9” (2.67 m)
  • Hull Draft  (motors up)1’ 8” (0.31 m) (motors down)2’ 9” (0.60 m)
  • Clearance w/Hard-Top  (from waterline)8’ 0” (2.40 m)
  • Clearance w/Windshield  (from waterline)6’ 7” (2.04 m)
  • Approx. Dry Weight  (w/twin 150 engines)5,896 lbs (2,674 kg) (w/twin 200 engines)6,130 lbs (2,781 kg) (w/single 350 engine)5,550 lbs (2,517 kg)
  • Fuel Capacity 139 U.S. gallons (526 L)
  • Fresh Water Capacity 18.5 U.S. gallons (70 L)
  • Livewell Capacity 30 U.S. gallons (113.51 L)
  • Fishbox Capacity 31 U.S. gal transom (117.3 L)
  • Max. Horsepower 400 hp (298 kw)
  • Deadrise 21°

*Net tank capacity.
The usable fuel capacity will be affected by several factors, including EPA-required fuel system components, temperature and loading of the boat. These factors will reduce the usable fuel capacity by approximately 10%.

Specifications as well as standard and optional equipment are subject to change without notice. All measurements approximate. For more information and pricing, please contact your Pursuit dealer.

Performance Reports
Single Yamaha® F350 Engine
Twin Yamaha® F200 Engines
Twin Yamaha® F150 Engines

C 260 Product Brochure - View Online
Full Line Product Catalog - View Online


The all new C 260 features an extensive list of standard equipment consistent with the award-winning product Pursuit has introduced in recent years.

Yacht-caliber fit and finish, timeless styling and modern appointments set the stage for a new generation of luxurious Pursuit Center Consoles.

All molded hatches throughout the boat are finished inside and out. Interior highlights include bow storage port and starboard, a thru-hull optional windlass system in the bow, forward opening head access and a custom surfboard styled, vacuum-infused hardtop.

The helm is protected by a curved, recessed acrylic windshield built to accent the stylish lines throughout the interior and exterior appointments.

Captain and crew share a double-wide adjustable leaning post/seat arrangement. Finished with such fishy details as a 30 gallon livewell, 31 gallon insulated fish storage box and separate cooler in the transom, visit your Factory Authorized Pursuit Dealer today to test drive a new C 260.


Standard Equipment

Effective date: AUGUST 1, 2016


  • Pursuit® Protection Plan:
    5-year hull/deck structural warranty
    5-year blister-free warranty
    2-year limited warranty
  • Reinforced infused FRP one-piece stringer grid
  • Pursuit custom diamond-pattern on all weather deck surfaces
  • Hardtop with spreader light and 4 silver rod holders
  • 2 - 3/8” 316L stainless steel stern eyes and 3/8” 316L stainless steel bow eye
  • Self-draining cockpit
  • Two 316L stainless steel bow grab rails
  • Retractable 3-step boarding ladder
  • 18” port stainless steel transom grab rail
  • Six 8” 316L stainless steel flush pull up cleats
  • Six stainless steel drink holders
  • High density PVC soft rubrail
  • Cockpit LED courtesy lights
  • Stbd 3/4” transom door with stainless steel latch
  • Cockpit breathable coaming bolsters
  • Alum. reinforcement plates for down rigger, aft gunwale, port and stbd
  • Molded split bow seating with finished fiberglass seat liners and covers with hinges and latches
  • Bow anchor storage with fiberglass hatch
  • Forward fishbox cushions


  • 12 v interior lighting with switch
  • Manual porcelain head with 13 gallon holding tank, macerator and deck pump out fitting
  • Molded fiberglass console headliner
  • Acrylic windshield
  • Fiberglass console door with stainless steel door latch, hinges and lock
  • Illuminated Carling® rocker switches
  • Fixed fiberglass helm with integrated helm footrest
  • Molded fiberglass leaning post: two seats with fold-down bolsters


  • Under gunwale rod storage racks
  • Four 316L stainless steel rod holders in gunwales
  • Fiberglass insulated 80 qt. cooler with fiberglass cover
  • 30 gallon Oceana blue circulating livewell located in helm seat base
  • Raw water washdown pump with deck fitting
  • 31 gallon fiberglass insulated transom fish box Bait prep Corian® cutting board


  • Single cylinder Teleflex hydraulic steering with fixed helm
  • 14” stainless steel steering wheel
  • U.S.C.G. and international lighting - LED 48” white tern light
  • Dual battery system with batteries, battery trays and Blue Seas® battery switch
  • 12 v electrical panel with breakers
  • Yamaha® fuel filter with primer bulb
  • Bennett® hydraulic trim tabs
  • U.S.C.G. and international lighting
  • Two 1500 gph Bilge pumps
  • Ritchie Helmsman® compass
  • Three Fire extinguishers
    18.5 gallon fresh water with transom mounted pull out sprayer
  • Horn
  • Pursuit meets all applicable USCG and NMMA standards
  • Yamaha® fuel management system
  • 316L stainless steel grab rail
  • One 12V outlet (1) and dual usb charger (1)
  • Helm fire extinguisher

Optional Equipment


  • Single Yamaha® F350 Electronic
    w/Power Steering
  • Twin Yamaha® F150hp Four-stroke
  • Twin Yamaha® F200 Electronic


  • Teleflex® Power Steering
    (standard with single 350 engine installed)
  • Windlass Anchor System
    (10’ 1/4” G4 chain / 150’ rope)
  • Stainless Steel Delta Plow Anchor
    (requires windlass opt)
  • Two Underwater LED Lights
    (blue/white combo)
  • Garmin Package (GPSMAP 7612XSV, Airmar B117 600 watt Transducer, NMEA 2000 Starter Kit, VHF 300, VHF Antenna Galaxy 5225XP, Custom Pursuit Dash Panel)


  • Pursuit Titanium Hull
  • Pursuit Cashmere Hull
  • Pursuit Navy Blue Hull
  • Pursuit Stars and Stripes Hull
  • Single Fresh White Painted Engine
    w/Platinum Graphics
  • Twin Fresh White Painted Engines
    w/Platinum Graphics
  • Boot Stripe Color - navy, black, red, scarlet,
    artic white/quartz grey, platinum
  • Boot stripe color - artic white/sand castle
    (only available with Cashmere hull color)
  • Sunbrella® Canvas Color
    (black, tweed, cadet grey or navy blue)
  • Helm Color - Titanium Standard
    (Cashmere, Navy Blue, Stars & Stripes)


  • Forward sunpad filler and cushion
  • Fiberglass bow table
  • Aft fold-down seat with cushion and raising backrest
  • Polk stereo with bluetooth streaming and 4 speakers
  • Portlight in Console (SS Window w/Screen)
  • PVC Rub Rail w/SS Insert
  • Tilt Hlem


  • Rupp® Revolution Top Gun Outriggers
    w/Telescoping Poles and Outrigger Kits
  • Side Wings (Connect to Gunnel)
  • 3 Piece Drop Curtain - Stamoid® (white)
  • Side Wings - Stamoid®
    (Connect to Gunnel - White)
  • 3 Piece Drop Curtain - Sunbrella®
  • Leaning Post Cover - Sunbrella®
  • Console Cover - Sunbrella®
  • Engine Cover (each) - Sunbrella®
